Our Gallery

Field documentation of NDT inspections, structural audits, and testing across East Africa.

Field Documentation

NDT Tests on Concrete Elements

6 images
Reinforcement Mapping
NDT-EA Limited

Reinforcement Mapping on an assumed column section

Rebar Scan
Schmidt Hammer Test
NDT-EA Limited

Schmidt Hammer Test at one of first floor slabs

Schmidt Hammer
Reinforcement Scanning
NDT-EA Limited

Reinforcement Scanning at one of the Ground Floor Beams

Rebar Scan
UPV Tests
NDT-EA Limited

Conducting UPV Tests at one of the ground floor columns

UPV Test
Foundation Columns
NDT-EA Limited

Inspection of Foundation Columns

Foundation
Trial Pits
NDT-EA Limited

Some of the Trial Pits exposing the Subsurface Material

Trial Pits
Equipment in Action
Typical NDT Tests

Mapping, Hammer & UPV Documentation

5 images
Reinforcement Mapping
NDT-EA Limited

Reinforcement Mapping on a column and beam sections

Rebar Scan
Schmidt Hammer
NDT-EA Limited

Schmidt Hammer Test on a column and a beam

Schmidt Hammer
UPV Tests
NDT-EA Limited

Conducting UPV Tests on Column and Slab elements

UPV Test
Substandard Works
NDT-EA Limited

Beam section indicating substandard corrective works

Defect Analysis
Substandard Concreting
NDT-EA Limited

Beam section depicting substandard works during concreting

Structural Defect
Thermal & Moisture Studies
Thermal Imaging & Moisture Detection

Structural Dampness Analysis

8 images
Damp Corner
NDT-EA Limited

Structural dampness at a corner section

Dampness
Heat Variation
NDT-EA Limited

Variation in heat absorption at one of the exterior sections

Thermal Imaging
RHS Dampness
NDT-EA Limited

A rear section depicting variation in structural dampness

Dampness
Bathroom Dampness
NDT-EA Limited

Structural Dampness at a bathroom

Moisture Survey
Bedroom Dampness
NDT-EA Limited

Structural Dampness at a bedroom

Moisture Survey
Washroom Dampness
NDT-EA Limited

Structural Dampness at one of the washrooms

Moisture Survey
LHS Dampness
NDT-EA Limited

Structural Dampness at a Section — LHS Accommodation Block

Accommodation
Extreme Ceiling Dampness
NDT-EA Limited

Extreme Structural Dampness — Washroom ceiling

Critical Finding
Structural Analysis
Scan Results

Reinforcement Bar Scans

3 images
First Floor Slab
NDT-EA Limited

Reinforcement Mapping — First Floor Slab, Grid H-M/1-2

Rebar Scan
Second Floor Beam
NDT-EA Limited

Reinforcement Mapping — Second Floor Beam M/8-11

Rebar Scan
Foundation Column Grid B-1
NDT-EA Limited

Reinforcement Mapping — Foundation Column Grid B-1

Foundation
